Product Description
Green Rooster DE 1000
Controllable, dimmable, 120-277V--- makes this lamp among the most versatile on the market!
Green Rooster Lighting 1000W Horticultural Digital Ballast is equipped with DE Technology and to be used with double ended lamps. Designed for medical, industrial or hobby horticulturalist.
It can be easily integrated into your existing grow room; simply replace your ballast & lamp with Green Rooster Lighting products and you will instantly achieve more useable grow light! More light = more yield!
The Green Rooster Lighting 1000W DE ballast has been designed in Germany to enable 400V DE Technology. This ballast is ONLY to be used with 400V and 240V lamps. However, we recommend to use 400V double ended lamps. which are superior to the 240V lamps traditionally used because of the increased efficiency and PAR spectrum output. Photosynthesis Active Radiation (PAR) refers to a specific part of the light spectrum that a plant actually uses photosynthesize light energy into growth energy.
FEATURES
●Extremely high frequency, works perfectly with Double-Ended lamps
●Has "soft start" program to allow multiple ballasts to start at the same time
●Dimming Options: 660W, 750W, 825W, 1000W, 1150W Double Ended HPS Lamps.
●Runs on 120 to 277 V power, 50 Hz or 60 Hz
●Works with both metal halide (MH) and high pressure sodium (HPS) lamps
●External breaker system protects against power surges
●Reflector with premium European(VEGA) aluminum, 95% reflectivity!
●Comes with a 10 ft power cord
●High quality, 3-year factory warranty
●UL Listed for safety.
Self-Protection
Input Protection:
High/Low Voltage; Lightening strike/inrush current; overcurrent; brownout;
Output Protection:
Open circuit; short circuit; end of lamp life; failure ignition; overvoltage; rectifying effect protection.
Overheat Soft-start:
In operation, inner heats will dissipate through case. When case temperature rises up to 85°C, ballast will gradually reduce power to 75%; when case temperature reach to 90°C, ballast will stop working until cool down to 70°C, then returns to full power status.
Dimmable:
660W, 750W,825W,1000W, 1150W
PERFORMANCE
|
|
| Input Power: 1150W |
| Input Voltage: 120V or 240V or 277V,50/60Hz |
| Input Current:9.10A/120V; 4.43A/240V; 3.8A/277V |
| Input Voltage Range: 95-305V |
| THD: <8% |
| Lamp CCF: <1.7 |
| Power Factor: >0.99 |
| Operating Frequency: >100kHz |
| Environment IP Require: >IP23 |
| Input current protection: Internal Fuse |
| Enclosure Temperature Rise: 35°C (95°F) |
| Ambient Temperature: -25 to 40°C (-13 to 104°F) |
| Ignition Voltage: <4KV |
| Open circuit Voltage: <300V |
| Lamp Flicker/Acoustic Resonance: No |
| RF Interference: No |
